Friday, 11 October 2013


Looking ahead to 2014 with the next release due in Q1 (codenamed Mira), Microsoft have indicated their CRM roadmap includes:
• Marketing Pilot Integration – to connect mid-market and enterprise level marketing automation with CRM including multi-channel campains
• Netbreeze Integration – connecting social listening and monitoring with CRM to analysis social sentiment among customers
• Enhancements to Microsoft Lync & Skype integration
• Case management and service level agreement enhancements
• Extended mobile device support

MSCRM 2013 Heighlights

  • Redesigned User Experience: Cleaner, faster, more intuitive interfaces with no pop ups or flipping from one application to the next.
  • Process Agility: Agile process guidance so you can respond to rapidly changing business needs.
  • CRM on the Go: New Windows 8 and iPad mobile applications that make your sales team smarter no matter where they are by delivering a seamless experience across the web and devices.
  • Social in Context: Work across boundaries to create the right customer experiences with the enterprise power of Yammer.
  • Base and Extension Tables - If you have been working with CRM in the past you are probably aware of the table splitting for each entity within CRM. With CRM 2013, the extension tables will be merged during the upgrade.
  • Server-side Synchronization - This new feature within CRM 2013 will allow administrators to easily manage the sync of email, appointments, tasks and contacts between versions of CRM and Exchange.
  • Access Teams - With the new feature of record-based Access Teams, you can add a user to the record and give them access.

MSCRM 2013 Image Data Types SDk

  • You can access images via a URL. The URL of the image is a read only value available via the SDK off of the Image as an absolute address. Image URLs behave in a similar fashion to Web Resources and Attachments. The primary difference is that images are returned as binary data and Web Resources and Attachments are returned as base-64 encoded MIME types.
  • ImageAttributeMetadata is being added to the MetadataService class. This class inherits from AttributeMetadata and represents the metadata for an attribute of type Image

  • Images can be returned as part of FetchXML queries or RetrieveMultiple calls. There will be an option to return binary data, URL, or both.
  • Binary data must be requested explicitly. A query that specifies “All” fields would only return the image URL. This accounts for the scenario where a user inadvertently queries all fields on an entity with a large number of images.
  • Microsoft Dynamics CRM for Outlook does not have direct support for images in CRM 2013 so images will not be synced. Image fields would be ignored in query results and offline view filters.

MSCRM 2013 Image Data type Storage

  • On upload via the web application or SDK, images are validated, resized, and stored as a common binary data format in the CRM database.
  • Regardless of upload format, all images are all formatted to JPG on create or update. On average, this puts most images at about 5k at max.
  •  The uploaded image is always resized to the minimum size necessary to support CRM 2013 and a smaller sized copy with the same aspect ratio as the original gets stored to the database.
  • The bounding box in CRM 2013 is hardcoded for all image fields: 144pixels x 144pixels. This value will be stored in attribute metadata as Height and Width

MSCRM 2013 Image Data Type Data Modeling

  • The display name can be set for images but SchemaName is always “entityImage” for any image-enabled entities and cannot be changed.
  • The image data type is not searchable.
  • A PrimaryImageAttribute metadata has been added to the entity.
  • Only a single image attribute can be defined per OOB/custom entities. This helps keep storage in check especially for CRM online customers.
  • PrimaryImageAttribute is set by default to the single “entityimage” attribute when it gets added to a custom entity. This is used to determine what image should be displayed in the header of the form. Note, that the grid does not display these images since that would require a smaller icon.
  •  If there are no image attributes on the specific entity OR the system customizer has selected not to display any image for the entity, the PrimaryImageAttribute value would be set to [None].

MSCRM 2013 Image Data Type

In CRM 2011, images are stored in notes as MIME encoded text. As a result, images get converted to a displayable format for every read and no pre-cached thumbnails exist. In CRM 2013, images are being introduced as a first class data type. You can now add images as a field, capture/store images and improve query operations on images.
You can capture and maintain images for User Profile, Contacts and Leads, and Account logos.

Data Modelling
·         Image data type as a field type to the application customization experience.
·         Support for only one Image field per entity.
·         Image stored as binary data in the CRM database.
·         Resize images server-side to conserve storage space and improve performance.
    § Original image uploaded not saved.
·         CRUD Operations
   § Support standard CRUD operations of Images the same as any other CRM data type.

   § Reference images via URL- ability to include URL and binary data in a RetrieveMultiple or   FetchXML call.

MSCRM 2011 Customizable Tooltips

In CRM 2011, tool tips are minimal and typically repeat the display name attribute of the field. These type of tool tips are useful for unlabeled UI, however most form fields have labels assigned to them and users need more information when entering or selecting data. Explanatory tooltips provide helpful text to address known user questions, explain terminology or concepts, and help end-users make good decisions to stay on task.

In CRM 2013, custom tooltips aim to improve the user experience by:

  •  Providing information on how to use and complete forms, right on the page.
  • Allowing organizations to display their business-specific information and processes to their users right in the CRM forms.

The system customizers can update tool tips when they are customizing an entity or entity attribute. The following points are to be noted:

Attribute Tool Tips
You can display entity attribute “Description” as tool tips on fields, buttons, etc. on existing forms for customizable entities. This will work against OOB and custom attributes.

Form Tool Tips
You can define tool tips to be displayed and the browser determines how the tool tip is displayed and for how long it would get displayed.

Rewritten Descriptions for Use as Tooltips – Refresh Forms
Specifically for Refresh Forms: All descriptions that can be displayed on the forms have now been rewritten for use as customizable tooltips.

Standard Customization Path
You can customize these tool tips simply by editing Description via the Settings > Customization UI> Form editor or field editor.

MSCRM 2013 New Phone Number Format

In the December 2012 Service Update, Phone Format was added for a number of telephone number fields on OOB entities. Most phone number fields in the OOB entities were also migrated as part of the release, but some fields, such as Fax number, did not get the Phone format.

In CRM 2013, this format with the label Phone Number is being added to the list of available formats in the attribute editor.
Fields with this format type enable a click-to-call experience for your telephony provider such as Lync or Skype.

Thursday, 10 October 2013

Parsing Whole Number value while Setting in MSCRM 2011

Int i;
if (Int32.TryParse(TextBox_Employees.Text, out i))
 mylead["numberofemployees"] = i;

Get selected Option Set value label in mscrm 2011 C#

                      RetrieveAttributeRequest request = new RetrieveAttributeRequest();
                       request.EntityLogicalName = targetEntity.LogicalName;
                       request.LogicalName = optionsetLogicalName;
                       request.RetrieveAsIfPublished = true;

                      RetrieveAttributeResponse response = (RetrieveAttributeResponse)service.Execute(request);
                       PicklistAttributeMetadata picklist = (PicklistAttributeMetadata)response.AttributeMetadata;

                       var query = from option in picklist.OptionSet.Options
                                   where option.Value == int.Parse(Statusvalue.ToString())
                                   select option.Label.UserLocalizedLabel.Label;
                        SselectedOptionSetlLabel = query.FirstOrDefault().ToString();

Monday, 7 October 2013

Limitations for Business Rules in MSCRM 2013

Limitations for Business Rules
·         Business rules in this release are intended to address common actions. Compared to what a developer can do using form scripts, business rules have limitations. However, business rules are not intended to replace form scripts.
·         The primary limitation you may find compared to form scripts is that all conditions in the Business rules are evaluated using AND. All the conditions must be true before the actions will be applied. There is no support for OR or Else operators to provide for more complex logic. To apply OR in your conditions you need to create separate rules for each condition you want to test. This can be done efficiently by using the Save As option and creating separate rules for each condition you want to test.
·         Business rules run only when the form loads and when field values change. They do not run when a record is saved.
·         Business rules work only with fields. Form scripts can interact with other visible elements such as tabs and sections within the form
·         When you set a field value using a business rule, any OnChange event handlers for that field will not run. This is to reduce the potential for a circular reference which could lead to an infinite loop.
·         If a Business Rule references a field that is not present on a form, the rule will simply not run. There will be no error message.
·         Calling other javascript web resources in the system via the business rule editor is not possible.

·         There is no ability to connect to external data sources.

Business Rules in MSCRM 2013 (Notes)

Miscellaneous Topics
·         Business rules cannot be run across different entities. They have to be defined within the same entity.
·         By default, the business rules are always created in a deactivated/draft state and must be activated to start executing for the form.
·         If there are multiple business rules for a control, the rules will run in the order they were added to the system. The last modified business rule runs last.
·         If you try to delete an attribute that has an active associated business rules, an error is triggered:
            "Process Error"
·         Business Rules can run on the web client (all browsers), Outlook (online and offline), iPad and CRM for tablets. However, they can only be customized through the Web Client or Outlook (Online/connected mode).
·         A new privilege for “Activate Business rules” under the customization tab for security roles has been added. Without activating the business rule first, it will not be executed.
·         Business Rules are imported/exported with the entities that they are attached to. It is not possible to export or import just a collection of business rules.
·         If there are multiple solutions, business rules will be run in the order in which the solutions were imported and the latest installed solution’s rules will run last.
·         If you package a managed/unmanaged solution, the states of the Business rules will be transported as is into the target system:
1.       activated rules will be activated
2.       deactivated rules will be deactivated

·         There are no limits on number of actions that can be attached to the business rule.

Bussiness Rule Configuration Actions in MSCRM 2013

Validate data and show error message rules

Data in fields (as values) can be validated and comparison can be made between different fields.
 If the action states throwing an error message, you can define the control that should display the message.

Show or Hide a field rules

 You can change whether the field is displayed in the form. The options are Show Field and Hide Field.
 These are applicable to only fields and not for tabs, sections or controls like web resources and iframes.
If you do not specify any conditions, this is similar to setting state by default.

Enable or disable field rules

The options are Lock and Unlock. When the field is locked, you will not be able to edit the value in the field.
 If you do not specify any conditions, this is similar to locking/unlocking the field by default.

Set field value rules

Choose the Field and Type. There are three types:


Use this type to set the value of one form field with the value of another field.

Use this type to set the value of a form field with a value you enter.

This option only appears for numerical or date data types. It does not appear for fields that contain text. Use this type to set the value to the result of a simple calculation that may use either a value in another form field or a value you enter.
 If you do not specify any condition, this is similar to setting a default value for the field.

Set field requirement rules

 The options are Not Business Required and Business Required. There is no option to set this to business recommended.
If you do not specify any condition, this is similar to setting the default business requirement state.

Friday, 4 October 2013

Quick Forms in MSCRM 2013

Quick Forms:

A quick form is a special type of CRM form that gives you the ability to display data from related entities onto the main form of any entity.

Quick forms will also be known as “Quick View Forms” since this form can be placed inside other main forms. They are rendered as read only so that quick form’s fields are not editable when placed on another form


·         These forms can be exported/imported as part of solutions.
·         These forms can be created/updated or deleted through the SDK.
·         Quick forms can be created/modified using the main form editor.
·         Only sections, spacers, fields and subgrids can be added.
·         A single column tab is used for quick forms and this cannot be changed.
·         No iframe or webresources are allowed.
·         Notes controls are not allowed.
·         There is no header or footer in quick forms.
